SP-300
Fast, sensitive, stable and modular
Maker
BioLogic (France)
Features
• 기본으로 2개의 슬롯 제공
• 전기화학실험 구성에 따라 단채널 또는 Bi-Stat으로 사용 가능
- 단채널로 사용 시, 여분의 슬롯에 4가지의 내장형 전류부스터 장착 가능
- Bi-stat으로 사용 시, RRDE 응용 또는 2개의 작업전극 독립적 동시 제어 가능
• Floating mode: 파이프라인, 그라운드 셀 및 오토 클레이브 응용 가능
• Potentiostat board 두 개를 장착하여 각각 독립적으로 사용 가능
• 사용자의 필요에 따른 다양한 옵션 장착 가능
• EIS board: 7 MHz to 10 µHz
• 내장형 calibration board: 언제든지 전류 및 전압 보정 가능
• Ultra low current option 장착 가능
• 다양한 전기화학 측정 테크닉 및 분석 툴 지원
• 실험 중 변수 수정 기능
• QCM, RDE, Spectrometer 등의 외부 기기와 연결하여 데이터 기록
Applications
• Renewable energy sources
• Fundamental electrochemistry
• Sensors
• Corrosion
• Electrolysis / anodizing
• Coatings
General Specifications
Slots available | Up to 2 |
Electrodes connections | 2,3,4,5 |
Compliance | ± 12 V |
Acquisition time | 1 µs with ARG option, 12 µs with EC-Lab developer package, 200 µs with EC-Lab |
Software | EC-Lab EC-Lab developper package EC-Lab Express |
Add-ons compatibility | Yes |
Dimension (W x D x H) | 205 x 410 x 225 mm |
Weight | 7.5kg |
Power requirement | 350W |
Interfaces | Ethernet (Direct, LAN, Wifi), USB 2.0 |
Channel Specifications : Control
Voltage | |
Ranges | Customizable ranges Adjustable from ± 10 V down to ± 30 mV Up to [0; 48] V with HCV-3048 |
Accuracy | < ± 1 mV ± 0.03 % of setting |
Resolution | From 1 µV (± 60 mV range) to 333 µV (± 10 V range) |
Current | |
Ranges | ± 1 A to 10 nA (9 ranges) up to 120 A with four HCV-3048 down to ± 1 pA using Ultra Low Current option |
Accuracy | < ± 0.1 % of range ± 0.03 % of setting |
Resolution | 0.004 % of the range : 760 fA (standard), 76 aA (Ultra Low Current option) |
EIS | |
EIS capability | 7 MHz to 10 µHz |
Frequency resolution | < 10 ppm of the setting |
EIS quality indicators | Yes |
* FSR : Full Scale Range
Advanced
Floating options | Floating, WE to ground, CE to ground |
Permeation (WE to ground) | Yes |
Multi-electrode (CE to ground) | Yes |
Filters | Hardware / Software |
Input / output | 2x analog inputs 1x analog output 3x TTL (trigger input/output, and safety) 2x monitor outputs (current and voltage) |
Stability control mode | 9 bandwidths |
Calibration | One calibration board included, more than 100 verified points |
FEATURES
• 기본으로 2개의 슬롯 제공
• 전기화학실험 구성에 따라 단채널 또는 Bi-Stat으로 사용 가능
- 단채널로 사용 시, 여분의 슬롯에 4가지 종류의 내장형 전류부스터 장착 가능
- Bi-stat으로 사용 시, RRDE 응용 또는 2개의 작업전극을 독립적으로 동시 제어 가능
• Floating mode: 파이프라인, 그라운드 셀 및 오토 클레이브 응용 가능
• Potentiostat board 두 개 장착하여 각각 독립적으로 사용 가능
• 사용자의 필요에 따른 다양한 옵션 장착 가능
• EIS board: 7 MHz to 10 µHz
• 내장형 calibration board: 언제든지 전류 및 전압 보정 가능
• Ultra low current option 장착 가능
• 다양한 전기화학 측정 테크닉 및 분석 툴 지원
• 실험 중 변수 수정 기능
• QCM, RDE, Spectrometer 등의 외부 기기와 연결하여 데이터 기록
APPLICATIONS
• Renewable energy sources
• Fundamental electrochemistry
• Sensors
• Corrosion
• Electrolysis / anodizing
• Coatings
SPECIFICATIONS
General | |
Slots available | Up to 2 |
Electrodes connections | 2,3,4,5 |
Compliance | ± 12 V |
Acquisition time | 1 µs with ARG option, 12 µs with EC-Lab developer package, 200 µs with EC-Lab |
Software | EC-Lab EC-Lab developper package EC-Lab Express |
Add-ons compatibility | Yes |
Dimension (W x D x H) | 205 x 410 x 225 mm |
Weight | 7.5kg |
Power requirement | 350W |
Interfaces | Ethernet (Direct, LAN, Wifi), USB 2.0 |
Channel specifications | ||
Control | Measurement | |
Voltage | ||
Ranges | Customizable ranges Adjustable from ± 10 V down to ± 30 mV Up to [0; 48] V with HCV-3048 | ± 10 V customizable |
Accuracy | < ± 1 mV ± 0.03 % of setting | < ± 1 mV ± 0.03 % of reading |
Resolution | From 1 µV (± 60 mV range) to 333 µV (± 10 V range) | 76 µV (7.6 µV for ± 250 mV, 0.76 µV for ± 25 mV, ZRA only) |
Current | ||
Ranges | ± 1 A to 10 nA (9 ranges) up to 120 A with four HCV-3048 down to ± 1 pA using Ultra Low Current option | 240 % of range value, except for the 1 A range (50 % of range) |
Accuracy | < ± 0.1 % of range ± 0.03 % of setting | < ± 0.1 % of range ± 0.03 % of reading |
Resolution | 0.004 % of the range : 760 fA (standard), 76 aA (Ultra Low Current option) | |
EIS | ||
EIS capability | 7 MHz to 10 µHz | |
Frequency resolution | < 10 ppm of the setting | |
EIS quality indicators | Yes |
* FSR : Full Scale Range
Advanced | |
Floating options | Floating, WE to ground, CE to ground |
Permeation (WE to ground) | Yes |
Multi-electrode (CE to ground) | Yes |
Filters | Hardware / Software |
Input / output | 2x analog inputs 1x analog output 3x TTL (trigger input/output, and safety) 2x monitor outputs (current and voltage) |
Stability control mode | 9 bandwidths |
Calibration | One calibration board included, more than 100 verified points |
