FEATURES

• 전압/전류 정밀도가 0.01% 로, 다음과 같은 실험을 위한 정밀한 데이터를 제공

               - Lifespan prediction, inventory efficiency, self-discharge, micro-reaction

• 다양한 셀 타입, capacitor  재료, half-cell,, 3전극, 코인 셀의 테스트를 지원

• 3중 보호(소프트웨어, 하드웨어, 펌웨어)로 장비와 샘플의 안전한 작동을 보장

• Multi-scan rate cyclic voltammetry(ERT Series available), linear sweep voltammetry(ERT Series available), GITT, PITT, CA, CP 같은 다양한 테크닉

• 온라인 calibration 및 간섭 없이 채널의 독립적인 작동

• 온도 제어, 표면 온도 모니터링, 3전극 설정 및 압력 감지를 위한 auxiliary 채널

             integration 이 가능

APPLICATIONS

• dQ/dV Analysis
• Accurate DCIR

• Electrochemical Workstation

• Accurate gram capacity

• Accurate Coulombic Efficiency
• Charge/Discharge Testing

• Comparison of impedance of  different cells

• Cell Cycle Impedance Analysis

TECHNICAL SPECIFICATIONS

	ECT6008 (0.01% High-Precision Series)
Type	ECT6008-5V100mA	ECT6008-5V6A		ECT6008-5V12A
Voltage	5V
Current Range	10nA~0.1mA 0.1mA~1mA 1mA~10mA 10mA~100mA	0.6μA~6mA 6mA~60mA 60mA~600mA 600mA~6A		1.2μA~12mA 12mA~120mA 120mA~1.2A 1.2A~12A
Temp. chamber	-20~80 ℃
Channel	8
Output	Four-Electrode Aviation Connector (Supports three-electrode testing with auxiliary voltage integration)
V&I Accuracy	±0.01% F.S.
Constant Power/Resistance Accuracy	±0.02% F.S.
Resolution	16bit
Input power	30W	500W/1000W
Operating Modes	Charge-Discharge Modes: Constant Current Charge/Discharge (CC) Constant Voltage Charge/Discharge (CV) Constant Current-Constant Voltage Charge/Discharge (CC-CV) Constant Power Charge/Discharge (CP) Constant Resistance Charge/Discharge (CR) DCIR (Direct Current Internal Resistance) Rate Charge/Discharge Electrochemical Modes: GITT (Galvanostatic Intermittent Titration Technique) PITT (Potentiostatic Intermittent Titration Technique) CA (Chronoamperometry) CP (Chronopotentiometry)
