MOS-DAD
Fast diode array spectrometer
Maker:
BioLogic (France)
FEATURES
Wavelength range : 190 to 1100 nm
Linear range from : 0 to 2 AU
Acquisition rate : 400 μs/spectrum
Fiber optics connection to stopped-flow
SPECIFICATIONS
| MMS UV-VIS | MCS UV-NIR | MCS UV | MCS UV-NIR | |
| Numbers of Diodes | 256 | 256 | 512 | 1024 |
| Wavelength range (nm) | 190 - 720 | 300 - 1100 | 190 - 610 | 190- 1000 |
| Spectral resolution | 2 nm/diode | 2 nm/diode | 0,8 nm/diode | 0,8 nm/diode |
| Max sampling rate | 0,4 ms/spectrum | 0,4 ms/spectrum | 0,8 ms/spectrum | 1,5 ms/spectrum |
| Linear signal range | 0 - 0,8 A.U. | 0 - 0,8 A.U. | 0 - 2 A.U. | 0 - 2 A.U. |
| Maximum number of Spectra | 2 500 | 2 500 | 1 500 | 750 |
| Wavelength accuracy | Better than 0,1 nm | |||
| Wavelength reproducibility | Better than 0,07 nm | |||
| Noise | Better than 1.10-4 A.U (single scan) Better than 1.10-5 A.U. (100 scans) | |||
| Stopped flow connection | Fiber optic | |||
| Includes | Diode array system, fiber optic and adaptor for stopped flow head, trigger cable, Sfit software, Biokine software | |||
| Light Source: not included but recommended | Deuterium Tungsten 30 W source for excitation from 200 nm to 1 100 nm | |||
| PC requirements (not included) | Compatible with windows XP, vista, 7 (32 ou 64 bits) with one available ethernet connection | |||
