SPFT2000


Single Particle Force Properties Test System


Maker:

IEST (CHINA)

  FEATURES


  • 배터리 소재 입자의 압축 강도를 테스트하여 재료의 압력 저항성을 평가


  • 데이터는 롤링 공정 시 재료의 파손이나 변형에 대한 정보를 제공


  •  재료의 물리적 강도를 확인하여 안정성에 대한 평가 가능




APPLICATIONS


  • Testing the crushing strength of battery

                 particle material


  • Evaluate the pressure resistance of the material


  • Guide the rolling process


  • Cycle stability Improvement by testing materials

                mechanical strength

TECHNICAL SPECIFICATIONS



Model
SPFT1000
SPFT2000
Test parameters
Displacement, pressure
Test range
Displacement: 0~80μm; Pressure: 0~100mN
Test accuracy
Displacement resolution: 1nm; Pressure resolution: 0.1mN
Stress-displacement cruve
•
•
Particle image observation
•
•
Automatic displacement platform
/
•
Automatic pressure control
•
•
Fully automatic software
•
•


Electrode Testing Solution

Electrode Integrated Testing Instrument

Maker

IEST (China)

Features

• Electrode Resistance Analyzer

• Online Electrode Resistance Analyzer

• Rolling Type Electrode Resistance Analyzer

• Electrode Integrated Testing Instrument

• Electrolyte Wetting Testing System

• Glove Box Type Electrode Resistance Analyzer

Applications

• Active material conductivity evaluation

• Conductivity evaluation of conductor types

• Evaluation of electrode primer technology

• Conductive agent distribution uniformity evaluation

• Uniformity evaluation of silicon-carbon hybrid material

• Analysis of electrode resistance during high temperature cycle & storage

Specifications

ModelBER2100
BER2200
Press
mode
Cylinder
Pipeline gas required,range:5-35MPa)
Testable
parameter
Resistance,
Pressure
Temperature
and humidity
Resistance,
Pressure

Temperature

and humidity

conductivity,

resistivity

Function

One point test

Constant

pressure

condition

Included BER2100
function
Automatic
measurement
software
ModelBER2300BER2500
Press
mode
Servo motor
(No pipeline gas required,
range:5-60MPa)
Testable
parameter
Resistance,
Pressure

Temperature

and humidity

conductivity,

resistivity

Resistance,

Pressure

Temperature

humidity,

conductivity,

resistivity,

thickness,

compaction

density

Function

Included

BER2100

function

Variable

pressure

Included

BER2300

function

Thickness

mesurement

Compaction

density

measurement
