FEATURES
TECHNICAL SPECIFICATIONS
| General | |
| Dimensions | 39 x 17 x 9 mm (L x W x H) |
| Operating Modes | Bipotentiostat, potentiostat |
| LED Indicators | Power on, cell on |
| DC Potential Range | ± 1.5 V |
| Compliance Voltage | ± 2.65 V |
| Maximum DC Current | ± 5 mA |
| Potentiostat | |
| Applied DC-potential Resolution | 250 µV |
| Applied Potential Accuracy | ≤ 0.1% |
| Current Ranges | 0.25 µA to 12.5 mA (5 ranges) |
| Current Accuracy | ≤ 0.1 % |
| Measured Current Resolution | 0.002% of current range (5 pA on 0.25 µA range) |
Multi-channel mode | |
| Multiplexing | Up to 256 devices (PC software control) |
| Other specifications | |
| Enclosure | Aluminum case |
| Weight | < 5 g |
| Power supply | USB (5 VDC / 20 mA max.) |
| Comm. interface | USB-C |
| Certifications | CE |
Electrode Testing Solution
Electrode Integrated Testing Instrument
Maker
IEST (China)
Features
• Electrode Resistance Analyzer
• Online Electrode Resistance Analyzer
• Rolling Type Electrode Resistance Analyzer
• Electrode Integrated Testing Instrument
• Electrolyte Wetting Testing System
• Glove Box Type Electrode Resistance Analyzer
Applications
• Active material conductivity evaluation
• Conductivity evaluation of conductor types
• Evaluation of electrode primer technology
• Conductive agent distribution uniformity evaluation
• Uniformity evaluation of silicon-carbon hybrid material
• Analysis of electrode resistance during high temperature cycle & storage
Specifications
| Model | BER2100 | BER2200 |
| Press mode | Cylinder Pipeline gas required,range:5-35MPa) | |
| Testable parameter | Resistance, Pressure Temperature and humidity | Resistance, Pressure Temperature and humidity conductivity, resistivity |
| Function | One point test Constant pressure condition | Included BER2100 function Automatic measurement software |
| Model | BER2300 | BER2500 |
| Press mode | Servo motor (No pipeline gas required, range:5-60MPa) | |
| Testable parameter | Resistance, Pressure Temperature and humidity conductivity, resistivity | Resistance, Pressure Temperature humidity, conductivity, resistivity, thickness, compaction density |
| Function | Included BER2100 function Variable pressure | Included BER2300 function Thickness mesurement Compaction density measurement |
